Ring Main Unit – Model 1
Ring Main Unit – Model 2
One of our Customized Products according to Egyptian Distribution company utility specification for infrastructure projects.
a ring main unit (RMU) is a factory assembled, a metal enclosed set of switchgear used at the load connection points of a ring-type distribution network. The metal enclosed unit connects to the transformer either through a bus throat of standardized dimensions, or else through cables and it is usually installed outdoors.
One of our Customized Products according to Egyptian Distribution company utility specification for infrastructure projects.
a ring main unit (RMU) is a factory assembled, a metal enclosed set of switchgear used at the load connection points of a ring-type distribution network. The metal enclosed unit connects to the transformer either through a bus throat of standardized dimensions, or else through cables and is usually installed outdoors.
Comby
Comby consumer units are designed to suit installations in domestic and commercial installations, easy to install, attractive and highly reliable. Fitted with either sheet steel flap or clear plastic flap for visual inspection of components. Complete with neutral and earth terminals and din rail.
PowerPac
.png)
A range of empty multi-purpose enclosures and enclosures with components mounted: load break switches, changeover switches, and switch fuses.
Empty enclosures are supplied with a blank component mounting plate (Aluzinc 1.5 mm)
Mirage
A range of empty multi-purpose enclosures and enclosures with components mounted: load break switches, changeover switches, and switch fuses.
Empty enclosures are supplied with a blank component mounting plate (Aluzinc 1.5 mm)
Mini Center Compact
Protecta
Unikit
.png)
Mini Center Compact Distribution boards, a design aimed for safety, reliability and availability in the electrical building installation.
Protecta Plus gives UK installers and designers the flexibility to cover all applications from standard installations to complex sites. Available in kit form for over-the counter-supply, the latest generation sub-distribution solution from ABB has been tailored to meet the needs of all segments of the building industry.
UNIKIT, the innovative enclosure system offers maximum safety,
functionality, flexibility, quick and simple assembly.
TriLine
Ar​Tu K
System Pro E Power
With the new, modular TriLine PowerModules system, STRIEBEL & JOHN is optimizing its range of low-voltage switchgear assemblies.
With the new, modular TriLine PowerModules system, STRIEBEL & JOHN is optimizing its range of low-voltage switchgear assemblies.
With the new, modular TriLine PowerModules system, STRIEBEL & JOHN is optimizing its range of low-voltage switchgear assemblies.
Oil Transformer
Medium Voltage SwitchBoard
Dry Transformer
Application : For Distribution System
Standards : IEC 60076-1,2,3,4,5 Parameters
Rated Voltage : 10.5,11,24KV
Rated Capacity : Up to 1.6MVA
Item : 12KV
Rated current of Busbar : 5000A
Rated Current of Switching Devices : 5000A
Rated Short Circuit Breaking Capacity (4S) : 50KA
Index or Protection (IP) : 4X
Partition Class : PM
Loss of Service Continuity (LSC) : LSC 2B
Internal Arc Classification (IAC) : 40 Ka,1 Sec
​
​
Item : 24KV
Rated current of Busbar : A3150A
Rated Current of Switching Devices : 3150A
Rated Short Circuit Breaking Capacity (4S) : 31.5 KA
Index or Protection (IP) : 4X
Partition Class : PM
Loss of Service Continuity (LSC) : LSC 2B
Internal Arc Classification (IAC) : 31.5 KA,1 Sec
​
​
Application : for Power Distribution System & Large Industrial Enterprises
Standards : IEC 60076-11 Parameters
Rated Voltage : 10.5,11,24KV
Rated Capacity : Up to 3MVA
Ring Main Unit (AIS)
Ring Main Unit (GIS)
.jpg)
Item : 12KV
Rated current of Busbar : 630A
Rated Current of Switching Devices :
-
630A (SF6 LBS FLN36-12D)
Rated Short Circuit Breaking Capacity (4S)
-
25 KA
Index or Protection (IP) : 4X
Item : 24KV
Rated current of Busbar : 630A
Rated Current of Switching Devices :
-
630 A (SF6 LBS FLN36-24D)
Rated Short Circuit Breaking Capacity (4S)
-
20 KA
Index or Protection (IP) : 4X
Item : 24KV
Rated current of Busbar : 1250A
Rated Current of Switching Devices :
-
LBS 630A
-
VCB 1250A
Rated Short Circuit Breaking Capacity (3S)
-
LBS 20KA
-
VCB 20KA
Index or Protection (IP) : 4X
Partition Class : PM
